$0.7154-6.9427 /Meter
| Type de paiement: | L/C,T/T |
| Incoterm: | FOB,CFR,CIF,EXW |
| Quantité de commande minimum: | 8000 Meter |
| transport: | Ocean |
| Hafen: | Qingdao |
Modèle: Pn12.5 Pn16 Pn20 Pn25
Lieu D'origine: Chine
Service De Traitement: Moulage, Coupe
Material: ppr
Nominal Pressure: 1.25MPa/1.6MPa/2.0MPa/2.5MPa
Length: 4M,or at request
Specification: 20-125mm
Feature: Flexible, High Pressure, Light Weight
Shape: Round
Color: White and Grey,Customized
After Sales Service: Support
| Unités de vente | : | Meter |
The file is encrypted. Please fill in the following information to continue accessing it
| Norminal diameter (mm) | S5 1.25MPa | S4 1.6MPa | S3.2 2.0MPa | S2.5 2.5MPa |
| Thickness（mm） | Thickness（mm） | Thickness（mm） | Thickness（mm） | |
| 20 | 2.0 | 2.3 | 2.8 | 3.4 |
| 25 | 2.3 | 2.8 | 3.5 | 4.2 |
| 32 | 2.9 | 3.6 | 4.4 | 5.4 |
| 40 | 3.7 | 4.5 | 5.5 | 6.7# |
| 50 | 4.6 | 5.6 | 6.9 | 8.3# |
| 63 | 5.8 | 7.1 | 8.6 | 10.5# |
| 75 | 6.8 | 8.4# | 10.3# | 12.5# |
| 90 | 8.2 | 10.1# | 12.3# | 15.0# |
| 110 | 10.0 | 12.3# | 15.1# | 18.3# |
| 125 | 11.4# | 14.0# | 17.1# | 20.8# |
